Cambium Networks
C024900C612 - Cambium ePMP 2.4 GHz Force 130 Point to Point, Wireless CPE Radio
C024900C612 - Cambium ePMP 2.4 GHz Force 130 Point to Point, Wireless CPE Radio
SKU:C024900C612
Regular price
$185.00 NZD
Regular price
Sale price
$185.00 NZD
Unit price
/
per
Shipping calculated at checkout.
* All prices exclude GST & Freight, Calculated at checkout - supply only*
Couldn't load pickup availability
Cambium ePMP 2.4 GHz Force 130 Point to Point, CPE radio. The Cambium Networks’ ePMP 2.4 GHz Force 130 is an affordable WISP subscriber module particularly well-suited for markets where price is key.
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.
Features
- Designed to operate in high interference environments and provides throughput of up to 140 Mbps with bi-directional traffic of real user data
- Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and low round-trip latency
- QoS management offers outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority
- Installation is a breeze for pole and wall mounting
- The ePMP Force 130 is compatible with ePMP 1000 Access Points
- Integrated 12 dBi 2.4GHz antenna
| Details | |
|---|---|
| Manufacturer's Code | C024900C612A |
| Frequency Range | 2402 - 2472 MHz |
| Channel Width | 5/10/20/40 MHz |
| MAC (Media Access Control) Layer | Cambium Proprietary |
| Physical Layer | 2x2 MIMO/OFDM |
| Ethernet Interface | 10/100 BaseT |
| Network Management | HTTPs, SNMPv2c, SSH |
| VLAN | 802.1Q with 802.1p priority |
| Transmit Power Range | +3 to 31 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Antenna Gain | 12 dBi |
| 3dB Beamwidth-Azimuth | 45 degrees |
| 3dB Beamwidth-Elevation | 15 degrees |
| Environmental | IP55 |
| Temperature | -30°C to +55°C |
| Weight | 0.35 kg |
| Wind Survival | 125 km/hour |
| Dimensions (H x W x D) | 235 x 77 x 58 mm |
| Pole Diameter Range | 38mm – 64mm |
| Power Consumption | 8 W Maximum, 5 W Typical |
| Input Voltage | 24 V; uses standard passive PoE injectors at 24V. Not compatible with 29V supplies |
| Details | |
|---|---|
| Power Supply | PoE Power Supply included |
| Mounting Hardware | (2) Cable Ties Included |
Specifications
Cambium ePMP 2.4 GHz Force 130 Point to Point, CPE radio. The Cambium Networks’ ePMP 2.4 GHz Force 130 is an affordable WISP subscriber module particularly well-suited for markets where price is key.
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.
Features
- Designed to operate in high interference environments and provides throughput of up to 140 Mbps with bi-directional traffic of real user data
- Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and low round-trip latency
- QoS management offers outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority
- Installation is a breeze for pole and wall mounting
- The ePMP Force 130 is compatible with ePMP 1000 Access Points
- Integrated 12 dBi 2.4GHz antenna
| Details | |
|---|---|
| Manufacturer's Code | C024900C612A |
| Frequency Range | 2402 - 2472 MHz |
| Channel Width | 5/10/20/40 MHz |
| MAC (Media Access Control) Layer | Cambium Proprietary |
| Physical Layer | 2x2 MIMO/OFDM |
| Ethernet Interface | 10/100 BaseT |
| Network Management | HTTPs, SNMPv2c, SSH |
| VLAN | 802.1Q with 802.1p priority |
| Transmit Power Range | +3 to 31 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Antenna Gain | 12 dBi |
| 3dB Beamwidth-Azimuth | 45 degrees |
| 3dB Beamwidth-Elevation | 15 degrees |
| Environmental | IP55 |
| Temperature | -30°C to +55°C |
| Weight | 0.35 kg |
| Wind Survival | 125 km/hour |
| Dimensions (H x W x D) | 235 x 77 x 58 mm |
| Pole Diameter Range | 38mm – 64mm |
| Power Consumption | 8 W Maximum, 5 W Typical |
| Input Voltage | 24 V; uses standard passive PoE injectors at 24V. Not compatible with 29V supplies |
| Details | |
|---|---|
| Power Supply | PoE Power Supply included |
| Mounting Hardware | (2) Cable Ties Included |
