HAC-HUM1220AP-0280P-PIR - Dahua - 1MP, Pinhole Covert, DWDR Camera, PIR Case - PAL
HAC-HUM1220AP-0280P-PIR - Dahua - 1MP, Pinhole Covert, DWDR Camera, PIR Case - PAL
SKU:DH-HAC-HUM1220AP-0280P-PIR
* All prices exclude GST & Freight, Calculated at checkout - supply only*
Low stock: 7 left
Features
Includes
- Max 30fps@1080P
- HD and SD output switchable
- 2.8mm fixed lens
- 12m/100 degrees detecting range/angle
- Two level detection sensitivity adjustable
- Built-in tamper switch
- DC12V
Specs
Model - HAC-HUM1220AP-0280P-PIR
Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Image Sensor |
1/2.9" CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels |
1920(H)X1080(V), 2MP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Minimum Illumination |
0.02Lux/F2.0(Color), 0.002Lux/F2.0(B/W) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio |
More than 65dB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Fixed lens / Fixed iris |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
Board-in |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
2.8mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max Aperture |
F2.0 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of View |
H: 100.5 degrees |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focus Control |
N/A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
500mm 19.7'' |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Note: The DORI distance is a - general proximity of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Definition |
Distance |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Detect |
25px/m (8px/ft) |
44m(143ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Observe |
63px/m (19px/ft) |
17m(57ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recognize |
125px/m (38px/ft) |
9m(29ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Identify |
250ppm (76px/ft) |
4m(14ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan / Tilt / Rotation |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
1080P (1920x1080) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output |
1-channel BNC high definition video output / CVBS video output (Can switch) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
Auto (Electronic) / Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
OSD Menu |
Multi-language |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC Mode |
BLC / HLC / DWDR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR |
DWDR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
AGC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
2D |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Auto / Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PIR |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Detection |
Passive infrared |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Detection Range |
12mx12m, 100 degrees, 19zones |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm prompt |
Red led, can be set to switch off |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sensitivity |
Two level (jumper) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pet immunity |
18Kg |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resistance light |
6500LUX |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation height |
DefaultĀ bracket, wall mount, 2.2-2.5m |
Certifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Certifications |
CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Interface |
N/A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
12V DC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
Max 0.7W (12V DC, IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environmental |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions |
-10C ~ +50C * Start up should be done at above -10C ( |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Conditions |
-10C ~ +50CĀ / Less than 90% RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ingress Protection & Vandal Resistance |
N/A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
Plastic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
120mmx62mmx58mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.13kg (0.29lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
0.18kg (0.40lb) |
