Cambium Networks
XV3-8 - Cambium 802.11ax Tri-Radio 8 x 8 Wi-Fi 6 MU-MIMO Access Point with Software-Defined Radios
XV3-8 - Cambium 802.11ax Tri-Radio 8 x 8 Wi-Fi 6 MU-MIMO Access Point with Software-Defined Radios
SKU:XV3-8
Regular price
$2,280.00 NZD
Regular price
Sale price
$2,280.00 NZD
Unit price
/
per
Shipping calculated at checkout.
* All prices exclude GST & Freight, Calculated at checkout - supply only*
Couldn't load pickup availability
The Cambium XV3-8X00A00-RW is an 802.11ax / WiFi6 Tri-Radio, 8x8 MU-MIMO Access Point with Software-Defined Radios.
The Cambium XV3-8 features a total of five (5) radios to deliver a next generation network with edge services with high capacity and high density. Three data radios can be configured as two 5 GHz 4x4 plus one 2.4 GHz 4x4, or the two 5 GHz radios can be combined into a single 5 GHz 8x8 radio with the maximum power and performance of the 802.11ax standard. A dedicated network scanning radio provides continuous network monitoring to enhance security protocols, detailed network reports, and automatic RF optimizations. Add the Bluetooth Smart 4.1 IoT radio for BLE-based location services and you get a multi-radio, high capacity Wi-Fi 6 AP designed for the most demanding networks in enterprise, education, retail, and public venues.
The Cambium XV3-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.
The Cambium XV3-8 features a total of five (5) radios to deliver a next generation network with edge services with high capacity and high density. Three data radios can be configured as two 5 GHz 4x4 plus one 2.4 GHz 4x4, or the two 5 GHz radios can be combined into a single 5 GHz 8x8 radio with the maximum power and performance of the 802.11ax standard. A dedicated network scanning radio provides continuous network monitoring to enhance security protocols, detailed network reports, and automatic RF optimizations. Add the Bluetooth Smart 4.1 IoT radio for BLE-based location services and you get a multi-radio, high capacity Wi-Fi 6 AP designed for the most demanding networks in enterprise, education, retail, and public venues.
The Cambium XV3-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.
Features
- Compatible with Cambium Networks XMS or cnMaestro management system
- High-density MU-MIMO Wi-Fi 6 with software-defined radios (SDR)
- Five-radio architecture for edge services
- 6 Gbps aggregate data rate
- Dedicated scanning sensor, dual band
- Application policy control
- EasyPass with Microsoft Azure and Google G Suite integration
- 5 Year limited lifetime warranty
| Details | |
|---|---|
| Product Code | XV3-8X00A00-RW |
| Radios | 2.4 GHz: 802.11 b/g/n/ax, 4x4; 5 GHz: 802.11 a/n/ac Wave 2/ax, 8x8 (or configure as two 4x4); 2.4/5 GHz scan, 1x1; BLE 4.1 |
| Wi-Fi | 802.11 a/b/g/n/ac Wave 2/ax |
| SSID Security | WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), Open |
| Max PHY Rate | 2.4 GHz: 1,147 Mbps, 5 GHz: 4,804 Mbps |
| Ports | 1 x IEEE 802.3 10/100/1000 Mbps, 1 x IEEE 802.3bz 100/1000/2500/5000 Mbps Auto sensing MDIX, 1 x USB 3.0 |
| Antenna | 2.4 GHz: 5 dBi, 5 GHz: 6.7dBi, 2.4/5 GHz: sensor 5 dBi / 6.3 dBi, BLE 5 dBi |
| Max EIRP | 2.4 GHz: 31 dBm, 5 GHz: 36 dBm |
| Power | Max power with USB/BLE, 35 W (802.3bt); 802.3at mode with USB/BT disabled; 12 VDC power, 2.1 mm barrel connector |
| Dimensions | 235 mm x 235 mm x 42 mm |
| Weight | 1,250 g |
| Ambient Operating Temperature | 0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature | -20ºC to 70ºC (-4ºF to 158ºF) |
| Humidity | 95% RH non-condensing |
| Mount Options | Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
| Details | |
|---|---|
| Power Supply | Sold Separately (N000000L142A) |
| Mounting Hardware | Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
Â
Â
Specifications
Â
Â
The Cambium XV3-8X00A00-RW is an 802.11ax / WiFi6 Tri-Radio, 8x8 MU-MIMO Access Point with Software-Defined Radios.
The Cambium XV3-8 features a total of five (5) radios to deliver a next generation network with edge services with high capacity and high density. Three data radios can be configured as two 5 GHz 4x4 plus one 2.4 GHz 4x4, or the two 5 GHz radios can be combined into a single 5 GHz 8x8 radio with the maximum power and performance of the 802.11ax standard. A dedicated network scanning radio provides continuous network monitoring to enhance security protocols, detailed network reports, and automatic RF optimizations. Add the Bluetooth Smart 4.1 IoT radio for BLE-based location services and you get a multi-radio, high capacity Wi-Fi 6 AP designed for the most demanding networks in enterprise, education, retail, and public venues.
The Cambium XV3-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.
The Cambium XV3-8 features a total of five (5) radios to deliver a next generation network with edge services with high capacity and high density. Three data radios can be configured as two 5 GHz 4x4 plus one 2.4 GHz 4x4, or the two 5 GHz radios can be combined into a single 5 GHz 8x8 radio with the maximum power and performance of the 802.11ax standard. A dedicated network scanning radio provides continuous network monitoring to enhance security protocols, detailed network reports, and automatic RF optimizations. Add the Bluetooth Smart 4.1 IoT radio for BLE-based location services and you get a multi-radio, high capacity Wi-Fi 6 AP designed for the most demanding networks in enterprise, education, retail, and public venues.
The Cambium XV3-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.
Features
- Compatible with Cambium Networks XMS or cnMaestro management system
- High-density MU-MIMO Wi-Fi 6 with software-defined radios (SDR)
- Five-radio architecture for edge services
- 6 Gbps aggregate data rate
- Dedicated scanning sensor, dual band
- Application policy control
- EasyPass with Microsoft Azure and Google G Suite integration
- 5 Year limited lifetime warranty
| Details | |
|---|---|
| Product Code | XV3-8X00A00-RW |
| Radios | 2.4 GHz: 802.11 b/g/n/ax, 4x4; 5 GHz: 802.11 a/n/ac Wave 2/ax, 8x8 (or configure as two 4x4); 2.4/5 GHz scan, 1x1; BLE 4.1 |
| Wi-Fi | 802.11 a/b/g/n/ac Wave 2/ax |
| SSID Security | WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), Open |
| Max PHY Rate | 2.4 GHz: 1,147 Mbps, 5 GHz: 4,804 Mbps |
| Ports | 1 x IEEE 802.3 10/100/1000 Mbps, 1 x IEEE 802.3bz 100/1000/2500/5000 Mbps Auto sensing MDIX, 1 x USB 3.0 |
| Antenna | 2.4 GHz: 5 dBi, 5 GHz: 6.7dBi, 2.4/5 GHz: sensor 5 dBi / 6.3 dBi, BLE 5 dBi |
| Max EIRP | 2.4 GHz: 31 dBm, 5 GHz: 36 dBm |
| Power | Max power with USB/BLE, 35 W (802.3bt); 802.3at mode with USB/BT disabled; 12 VDC power, 2.1 mm barrel connector |
| Dimensions | 235 mm x 235 mm x 42 mm |
| Weight | 1,250 g |
| Ambient Operating Temperature | 0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature | -20ºC to 70ºC (-4ºF to 158ºF) |
| Humidity | 95% RH non-condensing |
| Mount Options | Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
| Details | |
|---|---|
| Power Supply | Sold Separately (N000000L142A) |
| Mounting Hardware | Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
