Cambium Networks
C050900C813 - Cambium ePMP 5 GHz Force 300-19 PTP/CPE Radio
C050900C813 - Cambium ePMP 5 GHz Force 300-19 PTP/CPE Radio
SKU:C050900C813
Regular price
$355.00 NZD
Regular price
Sale price
$355.00 NZD
Unit price
/
per
Shipping calculated at checkout.
* All prices exclude GST & Freight, Calculated at checkout - supply only*
Couldn't load pickup availability
The Cambium ePMP™ Force 300-19 combines the latest 802.11ac Wave 2 technology and the field proven scalable performance of ePMP, the Force 300-19 delivers up to 600 Mbps of capacity.
The ePMP Force 300-19 is a powerful yet affordable subscriber module compatible with the ePMP3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.11ac Wave 2 technology.
The ePMP Force 300-19 is a powerful yet affordable subscriber module compatible with the ePMP3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.11ac Wave 2 technology.
Features
- Cambium Networks’ ePMP Force 300-19 is designed to operate in high interference environments and provides superior throughput of over 600 Mbps of real user data.
- The ePMP Force 300-19 supports channel sizes from 20MHz up to 80MHz and modulates up to 256 QAM.
- The ePMP Force 300-19 supports real time spectrum monitoring with out degradation in throughput
- Configurable modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 3-5 ms.
- QoS management offers an outstanding quality for triple play services – VoIP, video, and data – and provides three levels of traffic priority.
- The Integrated 19 dBi panel antenna has a small form factor and provides excellent range.
- Installations are quick and reliable supporting both pole and wall mounting.
- Perfect CPE for ePMP 3000 Point to Multi-Point solutions
- Free Cloud or on-premises network management with cnMaestro
- IP55 Outdoor Rated
- 3 Year Standard Warranty
| Details | |
|---|---|
| Manufacturer's Code | C050900C813A |
| Channel Width | 20/40/80 MHz |
| Proprietary Physical | Layer Air Interface on top of 802.11ac Wave 2 technology (2x2 MIMO/OFDM) |
| Channel Spacing | Configurable in 5 MHz increments |
| Frequency Range | Wide Band Operation 4910–5970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.) |
| MAC Layer (Media Access Control) | Cambium Proprietary |
| Ethernet Interface | 10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts |
| Protocols Used | IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Network Management | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro™ |
| VLAN | 802.1Q with 802.1p priority |
| Modulation | MCS0 (BPSK) to MCS9 (256 QAM 5/6) |
| Transmit Power Range | 0 to +28 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Antenna Gain | 19dBi |
| 3 dB Beamwidth Azimuth | 14.5º |
| 3 dB Beamwidth Elevation | 12.5º |
| Surge Suppression | 1 Joule Integrated |
| Environmental | IP55 |
| Temperature | -30°C to +60°C |
| Weight | 1.45 kg (Includes mounting bracket) |
| Wind Survival | 180 km/hour |
| Dimensions | 278 x 278 x 450 mm with mounting bracket attached |
| Pole Diameter Range | 25 - 41 mm with included clamp |
| Power Consumption | 12 W (Up to 15 W in extreme cold temperatures when heater is activated.) |
| Input Voltage | 30 V Passive PoE (14-30 V DC Input) |
| Encryption | 128-bit AES (CCMP mode) |
| Details | |
|---|---|
| Power Supply | 30V PoE Power Supply included |
| Pole/Wall Mount Bracket | Included |
Specifications
The Cambium ePMP™ Force 300-19 combines the latest 802.11ac Wave 2 technology and the field proven scalable performance of ePMP, the Force 300-19 delivers up to 600 Mbps of capacity.
The ePMP Force 300-19 is a powerful yet affordable subscriber module compatible with the ePMP3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.11ac Wave 2 technology.
Click here for more information about the complete Point to Multi-Point product range for Cambium ePMP 3000.
The ePMP Force 300-19 is a powerful yet affordable subscriber module compatible with the ePMP3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.11ac Wave 2 technology.
Click here for more information about the complete Point to Multi-Point product range for Cambium ePMP 3000.
Features
- Cambium Networks’ ePMP Force 300-19 is designed to operate in high interference environments and provides superior throughput of over 600 Mbps of real user data.
- The ePMP Force 300-19 supports channel sizes from 20MHz up to 80MHz and modulates up to 256 QAM.
- The ePMP Force 300-19 supports real time spectrum monitoring with out degradation in throughput
- Configurable modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 3-5 ms.
- QoS management offers an outstanding quality for triple play services – VoIP, video, and data – and provides three levels of traffic priority.
- The Integrated 19 dBi panel antenna has a small form factor and provides excellent range.
- Installations are quick and reliable supporting both pole and wall mounting.
- Perfect CPE for ePMP 3000 Point to Multi-Point solutions
- Free Cloud or on-premises network management with cnMaestro
- IP55 Outdoor Rated
- 3 Year Standard Warranty
| Details | |
|---|---|
| Manufacturer's Code | C050900C813A |
| Channel Width | 20/40/80 MHz |
| Proprietary Physical | Layer Air Interface on top of 802.11ac Wave 2 technology (2x2 MIMO/OFDM) |
| Channel Spacing | Configurable in 5 MHz increments |
| Frequency Range | Wide Band Operation 4910–5970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.) |
| MAC Layer (Media Access Control) | Cambium Proprietary |
| Ethernet Interface | 10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts |
| Protocols Used | IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Network Management | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro™ |
| VLAN | 802.1Q with 802.1p priority |
| Modulation | MCS0 (BPSK) to MCS9 (256 QAM 5/6) |
| Transmit Power Range | 0 to +28 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Antenna Gain | 19dBi |
| 3 dB Beamwidth Azimuth | 14.5º |
| 3 dB Beamwidth Elevation | 12.5º |
| Surge Suppression | 1 Joule Integrated |
| Environmental | IP55 |
| Temperature | -30°C to +60°C |
| Weight | 1.45 kg (Includes mounting bracket) |
| Wind Survival | 180 km/hour |
| Dimensions | 278 x 278 x 450 mm with mounting bracket attached |
| Pole Diameter Range | 25 - 41 mm with included clamp |
| Power Consumption | 12 W (Up to 15 W in extreme cold temperatures when heater is activated.) |
| Input Voltage | 30 V Passive PoE (14-30 V DC Input) |
| Encryption | 128-bit AES (CCMP mode) |
| Details | |
|---|---|
| Power Supply | 30V PoE Power Supply included |
| Pole/Wall Mount Bracket | Included |
